Brand New 2GIG 2GIG-DW10-345 Wireless Thin Door or Window Sensor, Battery Magnet
$55.99
Sale price
$55.99
Regular price
$69.99
- ✓ Type: Transmitter
- ✓ MPN: 2GIG-DW10-345
- ✓ Brand: 2gig
- ✓ High Quality & Large Capacity: Ensures long-lasting performance, meeting the continuous operation needs of the equipment.
- ✓ Stable Power Supply & Easy Replacement: Provides a stable power supply, allowing for quick and easy replacement.
- ✓ Money-Back Guarantee: We stand behind our products with a guarantee – and customer satisfaction are our priorities
- ✓ Product Details: Brand New 2gig 2gig-DW10-345 Wireless Thin Door or Window Sensor, Battery Magnet This contact is meant for use with the 2GIG Alarm System and can be installed on doors, windows and many other objects that open and close. The sensor transmits signals to the control panel when a magnet mounted near the sensor is moved away from or closer to the sensor. The sensor has an external input that accepts N/C dry contact devices. The sensor is also equipped with cover tamper for additional security. typical Specifications: Recessed Door Contact (2GIG-DW10-345) Wireless Signal Range 350 ft., open air, with 2GIG Wireless Alarm Control Panel Code Outputs Alarm; Alarm Restore; External Alarm; External Restore; Tamper; Tamper Restore; Supervisory; Low Battery Transmitter Frequency 345.000 MHz (crystal controlled) Transmitter Frequency Tolerance ± 15 kHz Transmitter Bandwidth 24kHz Modulation Type Amplitude Shift Keying-On/Off Keying (ASK-OOK) Unique ID Codes Over one (1) million different code combinations Supervisory Interval 70 minutes Peak Field Strength Typical 36,000 uV/m at 3m External Input Sampling Current 20 uA External Input Accepts N/C dry contact devices Reed Switch Magnetic Sensitivity 10 to 20 amp turns Reed Sensitivity 0.625 in. (1.59 cm) minimum gap, 0.85 in. (2.16 cm) typical Magnet Type Rare earth - ^^ Magnet Dimensions (LxWxH) 1.3 x 0.435 x 0.312 in. (3.3 x 1.1 x 0.79 cm) Sensor Dimensions (LxWxH) 2.59 X 1.03 X 0.49 in. (6.58 x 2.62 x 1.24 cm) Weight (including battery & magnet) 1.1 oz. (31.2 g) Housing Material ABS plastic Color White Operating Temperature 32° to 120°F (0° to 49°C) Relative Humidity 5-95% Non-Condensing Battery (included) Two (2) Panasonic CR2032, or equivalent Lithium batteries Regulatory Listing(s) ETL, FCC Part 15, Industry Canada Warranty* Two (2) years Included Accessories Two (2) Phillip's flat-head screws, one (1) two-pin connector with a 12" flying 2-wire lead, adhesive strip
